Guide Thermal imaging camera TE211M

Guide TE211M
The TE Mini Series handheld thermal imaging monocular, your pocket-sized night vision companion, is equipped with a 256×192 infrared detector and a 10 mm lens, offering a detection range of up to 500 metres. The integrated 1.43-inch AMOLED colour touchscreen allows you to see infrared images clearly without pressing your eyes against the eyepiece, reducing eye fatigue during prolonged use. With just a 10-minute quick charge, it offers up to 1 hour of continuous operation, making it the ideal companion at your side.

Powerful 12μm detector – sharp image quality
Equipped with a powerful 12μm detector, the TE Mini delivers razor-sharp image quality that distinguishes targets from their surroundings even in darkness. Ultimate lightweight - Effortlessly portable
The TE Mini weighs only approx. 200 grams and has a compact, pocket-sized design that is smaller than a mobile phone and thinner than a wristwatch, offering a comfortable grip and exceptional mobility. Details determine success:
The ultimate precision of infrared thermal imaging technology Game-changing – large touchscreen
The TE Mini features an innovative large touchscreen that provides a direct, ultra-clear display and seamless touch control. Users can select functions by simply swiping through the menu and using simple touch operations. Smooth operation – simplified interaction
Based on years of outdoor experience, the TE Mini features an extremely slim button design. With just one button and a ring, users can easily access the menu and perform various functions. Advanced battery - 20 W fast charging
The TE Mini has a built-in battery that provides up to 6 hours of runtime. It features an advanced 20W fast charging function. With just a 10-minute quick charge, you can enjoy 1 hour of uninterrupted use, ensuring worry-free power.

Specifications

•

  The sensor resolution is 256×192@12μm
  Thermal sensitivity - NETD 30mK
  The frame rate is 50 Hz
  Lens - 10mm, F1.0
  Field of view – 13.1°×13.1°
  FOV m@100m – 23×23
  Zoom - 1.2x~4.8x
  Detection distance 500m
  Focus - No focus
  Screen type -Touchscreen, AMOLED 466×466
  Color palettes - white hot, black hot, red hot, green hot, iron red, blue hot, sepia
  WIFI – 2.4G, 5G
  Interface USB Type-C, supports charging
  Others Microphone, Bluetooth
  Recording function Photo / Video (with audio recording)
  Memory capacity - 16GB
  Battery type - Built-in battery
  Operating time 6 hours (20W fast charging supported)
  Working temp. -20°C to 50°C / -4°F to +122°F
  Protection - IP67
  Weight (g) – 200
  Size (mm) – 49×49×111
